100L 6″ Tri-Clamp Sanitary Keg w/ Dip Tube – V2


100L 6″ Tri-Clamp Sanitary Keg w/ Dip Tube – V2

Our USA Lab 100L Keg comes standard with a 6″ Tri-Clamp Lid that has a 2″ Tri-Clamp Center Port, a 1/4″ FNPT Dip Tube, and a 1/2″ FNPT Port. This allows for users to customize the keg to be used as a collection vessel, storage tank, and much more. The 6″ Lid with tri clamp dip tube is included!
***The Dip Tube on this product goes from 1/2 FNPT (12.7mm) to 8mm Tubing***

Material: 304 Stainless Steel
Capacity: 100L
Lid Size: 6″ Tri-Clamp
•PSI Rating: 45psi
Lid Connections: (1x 1/2″ FNPT) (2x 1/2″ FNPT w/ Dip Tube) (1x 1/4″ FNPT) (1x 2″ TC)
Top Connection: 2pcs 1.5″ Tri-Clamp
Drain Connection: 1.5″ Tri-Clamp
Exterior Dimensions: 16″ L x 16″ W x 37″ H
Weight: 71lbs




100L Sanitary Keg 1pc
1.5″ Poly Sight Glass 2pcs
1.5″ Solid End Cap 1pc
6″ Buna-N Gasket 1pc
1.5″ Buna-N Gasket 3pcs
6″ Standard Pressure Tri-Clamp 1pc
1.5″ Standard Pressure Tri-Clamp 3pcs
6″ Lid with 2x 1/2″ FNPT w/ Dip Tube, 1x 1/2″ FNPT, 1x 1/4″ FNPT,1x 2″ TC 1pc
